Product Summary
The OP484FS is a single, dual, and quad single-supply, 4 MHz bandwidth amplifier featuring rail-to-rail inputs and outputs. The OP484FS is guaranteed to operate from 3 V to 36 V (or ±1.5 V to ±18 V). The applications of the OP484FS include Battery-powered instrumentation, Power supply control and protection, Telecommunications, DAC output amplifier and ADC input buffer.
Parametrics
OP484FS absolute maximum ratings: (1)Supply Voltage: ±18 V; (2)Input Voltage: ±18 V; (3)Differential Input Voltage:±0.6 V; (4)Output Short-Circuit Duration to GND: Indefinite; (5)Storage Temperature Range: -65 to +150℃; (6)Operating Temperature Range: -40 to +125℃; (7)Junction Temperature Range: -65 to +150℃; (8)Lead Temperature(Soldering 60 sec): 300℃.
Features
OP484FS features: (1)Single-supply operation; (2)Wide bandwidth: 4 MHz; (3)Low offset voltage: 65 μV; (4)Unity-gain stable; (5)High slew rate: 4.0 V/μs; (6)Low noise: 3.9 nV/Hz.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() OP484FS |
![]() |
![]() IC OPAMP GP R-R 4.25MHZ 14SOIC |
![]() Data Sheet |
![]()
|
|
||||||||||||||||
![]() |
![]() OP484FS-REEL |
![]() |
![]() IC OPAMP GP R-R 4.25MHZ 14SOIC |
![]() Data Sheet |
![]()
|
|
||||||||||||||||
![]() |
![]() OP484FS-REEL7 |
![]() |
![]() IC OPAMP GP R-R 4.25MHZ 14SOIC |
![]() Data Sheet |
![]()
|
|
||||||||||||||||
![]() |
![]() OP484FSZ-REEL |
![]() |
![]() IC OPAMP GP R-R 4.25MHZ 14SOIC |
![]() Data Sheet |
![]()
|
|
||||||||||||||||
![]() |
![]() OP484FSZ-REEL7 |
![]() |
![]() IC OPAMP GP R-R 4.25MHZ 14SOIC |
![]() Data Sheet |
![]()
|
|
||||||||||||||||
![]() |
![]() OP484FSZ |
![]() |
![]() IC OPAMP GP R-R 4.25MHZ 14SOIC |
![]() Data Sheet |
![]()
|
|
