Product Summary

The BTA06-600B is snubberless, logic level & standard 6A triac. The BTA06-600B can be used as an ON/OFF function in applications such as static relays, heating regulation, induction motor starting circuits or for phase control in light dimmers, motor speed controllers. The BTA06-600B is specially recommended for use on inductive loads, thanks to their high commutation performances.

Parametrics

BTA06-600B absolute maximum ratings: (1) RMS on-state current (full sine wave) , IT(RMS) : 6A ; (2) Non repetitive surge peak on-state current (full cycle, Tj initial = 25°C) ITSM : 60A; (3) I t Value for fusing It: 21As (tp=10ms) ; (4) Critical rate of rise of on-state current I= 2 x I , tr ≤100 ns: 50A/μS; (5) Peak gate current: 4A; (6) Average gate power dissipation: 1W; (7) Storage junction temperature range: -40 to +150°C, Operation Junction temperature range: -40 to +125°C.

Features

BTA06-600B features: (1) IT (RMS) : 6A; (2) VDRM/VRRM: 600 and 800V; (3) IG (Q1) : 5 to 50mA.

Diagrams

BTA16-600B Circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BTA16-600B
BTA16-600B
Other

Data Sheet
Negotiable
BTA16-600BRG
BTA16-600BRG
STMicroelectronics
Triacs 16 Amp 600 Volt
Data Sheet
0-1: $0.85
1-10: $0.76
10-100: $0.70
100-250: $0.62
BTA16-600BW3G
BTA16-600BW3G
ON Semiconductor
Triacs 16A 50mA 600V IGT 3 QUAD INTERNL ISLTD
Data Sheet
0-1: $0.82
1-25: $0.80
25-100: $0.64
100-250: $0.57
BTA16-600BWRG
BTA16-600BWRG
STMicroelectronics
Triacs 16 Amp 600 Volt
Data Sheet
0-1: $0.71
1-10: $0.63
10-100: $0.58
100-250: $0.51
BTA16-600BW
BTA16-600BW

TRIAC 600V 16A TO-220AB
Data Sheet
Negotiable
