Product Summary

The UTC TIP122 is an NPN epitaxial transistor, designed for use in general purpose amplifier low-speed switching applications.

Parametrics

TIP122 absolute maximum ratings: (1) Collector to Base Voltage VCBO: 100V; (2) Collector to Emitter Voltage VCEO: 100V; (3) Emitter to Base Voltage VEBO: 5V; (4) IC Collector Current IC: 5V; (5) Junction Temperature Tj: +150°C; (6) Storage Temperature Tstg: -55 to +150°C.

Diagrams

TIP122 Block Diagram
