Product Summary

The K9F2G08UOA-PCBO is a 2G-bit NAND Flash Memory with spare 64M-bit. NAND cell of the K9F2G08UOA-PCBO provides the most cost-effective solution for the solid state application market. A program operation of the K9F2G08UOA-PCBO can be performed in typical 200μs on the (2K+64) Bytepage and an erase operation can be performed in typical 1.5ms on a (128K+4K) Byte block. The K9F2G08UOA-PCBO is an optimum solution for large nonvolatile storage applications such as solid state file storage and other portable applications requiring non-volatility.

Parametrics

K9F2G08UOA-PCBO absolute maximum ratings: (1) Voltage on any pin relative to VSS: VCC: -0.6 to +2.45V, -0.6 to +4.6V, VIN: -0.6 to +2.45V, -0.6 to +4.6V, VI/O: -0.6 to Vcc +0.3 (<2.45V) , -0.6 to Vcc +0.3 (<4.6V); (2) Temperature Under Bias: -10 to +125°C; (3) Short Circuit Current IOS: 5mA.

Features

K9F2G08UOA-PCBO features: (1) Voltage Supply : 1.65V to 1.95V; (2) Memory Cell Array : (256M + 8M) x 8bit; (3) Automatic Program and Erase; (4) Page Read Operation; (5) Fast Write Cycle Time; (6) Command/Address/Data Multiplexed I/O Port; (7) Hardware Data Protection; (8) Reliable CMOS Floating-Gate Technology; (9) Command Driven Operation; (10) Unique ID for Copyright Protection.

Diagrams

K9F2G08UOA-PCBO Pin Configuration
