Product Summary

This data sheet provides complete design documentation for the second-generation devices of the TMS320 family. This facilitates the selection of the devices best suited for user applications by providing all specifications and special features for each TMS320 member. This data sheet is divided into four major sections: architecture, electrical specifications (NMOS and CMOS), timing diagrams, and mechanical data. In each of these sections, generic information is presented first, followed by specific device information. An index is provided for quick reference to specific information about a device.

Features

? 128K Words of Data/Program Space
? 32-Bit ALU/Accumulator
? 16 × 16-Bit Multiplier With a 32-Bit Product
? Block Moves for Data/Program
Management
? Repeat Instructions for Efficient Use of
Program Space
? Serial Port for Direct Codec Interface
? Synchronization Input for Synchronous
Multiprocessor Configurations
? Wait States for Communication to Slow
Off-Chip Memories/Peripherals
? On-Chip Timer for Control Operations
? Single 5-V Supply
? Packaging: 68-Pin PGA, PLCC, and
CER-QUAD
? 68-to-28 Pin Conversion Adapter Socket for
EPROM Programming
? Commercial and Military Versions Available
